FEATURES

1.The pressure-assisted seal design provides tight shutoff and permits the use of smaller actuators in applications requiring full ASME B16.34 shutoff capabilities.

2.Shaft-blowout protection is designed into the A31D valve.

3.The optional ENVIRO-SEAL™ packing system is designed with improved sealing, guiding, and loading force transmission.

4.This valve will meet your actuator needs with a choice of splined or keyed shaft connections.

5.Trim and bolting materials are available for applications involving sour liquids and gases.

SPECIFICATIONS

Certifications

PED, CRN, Fugitive Emission, NACE, ATEX, CUTR, Fire Safe

Critical Service

General Service

Flow Characteristics

Linear

Material

Carbon Steel, Stainless, Alloy

Operating Temperature

Standard Temperature, High Temperature

Pressure Class

ASME

Process Connection Type

Double Flanged

Shutoff Class

Class VI (FCI 70-2), MSS SP-61

Valve Size

NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 12

Valve Size Standard

NPS
