FEATURES

1.A flow-straightening, vaned seat ring is available to offer open- and closed-loop performance and may be used as a direct replacement for the non-vaned seat ring.

2.Complies with the Clean Air Act with ENVIRO-SEAL™ packing systems.

3.The process fluid flows through the trim, flushing away solid deposits above and below the guide bushing, thus reducing the possibility of a sticking valve plug.

4.Quick-change trim, with a clamped-in seat ring, reduces the disassembly time.

5.Low-flow requirements can be satisfied with standard restricted-capacity trim or with Micro-Form, Micro-Flute, or Micro-Flow valve plugs.

SPECIFICATIONS

Certifications

SIL capable, Fugitive Emission, NACE

Critical Service

Noise Abatement, Dirty Service, Steam Condition, Erosive, Low Flow, Corrosive, General Service, Outgassing, Flashing

Flow Characteristics

Equal percentage, Linear, Special Characterization, Quick Opening

Material

Carbon Steel, Stainless, Duplex, Alloy

Operating Temperature

Standard Temperature

Pressure Class

PN, ASME

Process Connection Type

Flanged, Butt Weld, RTJ, Threaded, Socket Weld

Shutoff Class

Class IV (FCI 70-2), Class V (FCI 70-2), Class VI (FCI 70-2)
