FEATURES

1.Controlled compression of standard seat construction protects PTFE disk between metal disk seat and disk retainer.

2.Rugged cage guiding provides high valve plug stability, which reduces vibration and mechanical noise.

3.Increased wear resistance of hardened stainless steel trim means longer-lasting service.

4.Valves are available with dimensions specified by EN/DIN standards.

SPECIFICATIONS

Certifications

SIL capable, Fugitive Emission, NACE

Critical Service

Noise Abatement, Cavitation, Steam Condition, Erosive, Low Flow, Corrosive, General Service, Outgassing, Flashing

Flow Characteristics

Equal percentage, Linear, Special Characterization, Quick Opening

Material

Carbon Steel, Stainless, Duplex, Alloy

Operating Temperature

Standard Temperature

Pressure Class

PN, ASME

Process Connection Type

Flanged, Butt Weld, RTJ, Threaded, Socket Weld

Shutoff Class

Class IV (FCI 70-2), Class V (FCI 70-2), Class VI (FCI 70-2)

Valve Size

NPS 1 through NPS 30
