FEATURES

1.Improved Cage Design – Drilled-hole cages, offering excellent strength and additional resistance to destructive vibration, are standard.

2.Piping Economy – The availability of expanded end connections on EH valves may eliminate the need for line swages while accommodating oversized piping arrangements.

3.O-ring Seat Ring Gasket Construction – Use of O-ring construction provides excellent shut-off with minimal seat ring installation torques for temperatures up to 232C (450F). O-ring construction is standard on EHT valves.

SPECIFICATIONS

Valve Type

Angle,Globe

Material

Alloy,Carbon Steel,Cast Iron

Application

Cavitation, Corrosive, Dirty Service, Erosive, Flashing, General Service, Low Flow, Noise Abatement

Pressure Class

ASME,PN

Certifications

ATEX,CRN,CSA,CUTR,FM,Fugitive Emission,IECEx,NACE,PED,SIL capable

Operating Temperature

High Temperature,Standard Temperature
