FEATURES

1.The pressure-assisted seal design provides tight shutoff against the full pressure rating of the specified valve.

2.The anti-blowout gland fits securely over the valve shaft, which has been turned down to form a circumferential shoulder that contacts the anti-blowout gland.

3.A splined end connection on the drive shaft allows lever clamping by most Fisher rotary actuators.

4.Optional keyed shaft is ideal for on/off applications and allows actuator selection flexibility.

SPECIFICATIONS

Certifications

SIL capable, PED, CRN, Fugitive Emission, NACE, ATEX, CUTR, Fire Safe

Critical Service

General Service

Flow Characteristics

Linear

Material

Carbon Steel, Stainless, Alloy

Operating Temperature

Standard Temperature, High Temperature, Cryogenic

Power Source

Electric, Hydraulic, Pneumatic, Electro-Hydraulic

Pressure Class

ASME

Process Connection Type

Flanged, Single Flanged, Double Flanged, Lugged, Wafer

Seat / Seal Type

Metal, Soft
