FEATURES

1.High-Pressure Capabilities

2.Rugged Construction

3.Better Low-Pressure Control

4.Sour Gas Service Capability

SPECIFICATIONS

Body Size and End Connection Styles

NPS 1 and 2 / DN 25 and 50 with an end connection of NPT, ASME CL150 RF, CL300 RF, or CL600 RF

Maximum Inlet Pressure

1500 psig / 103 bar

Maximum Outlet Pressure

Up to 500 psig / 34.5 bar

Outlet Pressure Range

3 to 500 psig / 0.21 to 34.5 bar in 10 ranges

Pressure Registration

Internal
