FEATURES

1.Low Differential Applications—Can accurately control at pressure differentials as low as 1 psid / 70 mbar d

2.Precise Pressure Control—Provides stable and accurate downstream pressure control regardless of load changes or inlet pressure variations.

3.Quiet Operation—The Whisper Trim™ Cage option reduces noise by up to 30 dBa.

_{4.Easy In-Line Maintenance}—Top entry design enables easier maintenance. Trim parts can be inspected, cleaned and replaced without removing the body from pipeline.

SPECIFICATIONS

Body Sizes and End Connection Styles

Body Sizes: NPS 1, 2, 3, 4, 6, 8 x 6, 12 x 6 / DN 25, 50, 80, 100, 150, 200 x 150, 300 x 150

Maximum Inlet Pressure

400 psig / 28 bar or body rating limit whichever is lower
