FEATURES

1.Wide Variety of Body Sizes and End Connections

2.Fixed Factor / Pressure Factor Measurement (PFM) Accuracy Capabilities

3.Field Convertible from Internal Sensing to External Sensing for Wide-Open Monitor Construction

4.Available in Gray Cast Iron, Ductile Iron, and Steel Body Materials

5.Only Standard Tools Required for Pressure Adjustment and Orifice Removal

SPECIFICATIONS

Maximum Operating Inlet Pressure

125 psig / 8,6 bar

Outlet Pressure Range

3.5-inches w.c. to 5.5 psig / 9 to 380 mbar in nine ranges

Maximum Emergency Outlet Pressure (Casing)

25 psig / 1,7 bar

Maximum Outlet Pressure to Avoid Internal Parts Damage

5 psi / 0,34 bar over set point

Maximum Operating Outlet Pressure

5.5 psig / 380 mbar

Pressure Registration

Internal or External
