SPECIFICATIONS

Size

2''through 24''(50 through 600 mm)

Ratings & Connections

Flanged: ANSI 150 – 2500, UNI-DIN 10 - 400

Welded: BW or SW

Screwed: NPT 2''(50 mm)

Body Materials

carbon steel; stainless steel; chrome-moly

Actuators

model 87/88 multi-spring diaphragm; 51/52/53 piston-cylinder

Trim

balanced cage-guided trim; Lo-dB, anti-cavitation and VRT (Variable Resistance Trim), single and multiple cages are available

Inherent Characteristics

linear or equal percentage
