SPECIFICATIONS

Size

1''through 10''(25 through 250 mm)

Ratings & Connections

Flanged: ANSI 150 – 600, UNI-DIN 10 -100

Threaded: NPT 3/4''through 2''(20 through 50 mm)

Welded: BW or SW, ANSI 900 - 2500 on request

Body Materials

carbon steel; stainless steel; chrome-moly

Actuators

model 87/88 multi-spring diaphragm; model 37/38 spring diaphragm; cylinder

Trim

v-port plug

Inherent Characteristics

linear
