Features

1.Lead-free versions are available to comply with Safe Drinking Water Act regulations

2.Low-temperature models control cryogenic fluids, including liquid nitrogen (-320° F/-194° C), liquid argon (-303° F/-184° C), and liquid oxygen (-297° F/-181° C)

3.Valves can be specified for hot water service to 210 ° F / 95 ° C for in laundry, boiler and heat exchanger applications

4.Ideal for high-pressure control applications in commercial and industrial gas burners

Specifications

alve Actuation：Solenoid

Body Material：Brass, Stainless Steel, Lead-free Brass, 316 stainless steel on request

Media：Aggressive Liquids/Gases, Air, Inert Gas, Ammonia, Cryogenic, Fuel Oil, Hot Water, Light Oil, Liquid Propane Gas, Natural Gas, Oxygen, Steam, Vacuum, Water

Pipe / Port Size：1/2 "; 3/8 "; 3/4 "; 1 "; 1 1/4 "; 1 1/2 "; 2 "; 2 1/2 "

Port Type：NPTF, G (ISO 228/1)

Function：2 way - 2/2 Normally Closed, 2 way - 2/2 Normally Open

Flow：From 1.3 to 39 Kv , 1.5 to 45 Cv

The Related Products:

210 Series

EF8210D014 24DC

EF8210G089 24DC

EF8210G089 220AC

EF8210G034 220AC

VCEFCM8210G037 24DC

327 Series

NF8327B212.24/DC

NF8327B011.230/50-60

NFET8327B232 24VDC

NFET8327B202 24VDC

NF8327B011 24VDC

NF8327A608 230V/50HZ

NF8327B112/24V

NF8327B102 24DC

WSNFIS8327B312 24DC

WSNF8327B122 24DC

WSNF8327A608

WSNF8327B312

WSNF8327B112MO

WSNF8327B202

WSNFET8327B102 24VDC

EF8327G041 220AC

551 Series

NF8551B401MO 220AC

NF8551B418 220AC

NF8551B402 220AC

NF8551B418MO 220AC

NF8551B402MO 220AC

NFG551A409MO 24DC

WSNF8551A322MO

WSNF8551A309MO

EF8551A001MS 24V

EF8551A001MS

VCEFCMG551H301MO 24DC

JPIS8551B321MO 24DC

531 Series

EF8531G301MO 24VDC

JPISG531B301 24DC

JPIS8531B301MO 24DC

553 Series

NF8553A417MO DC24V

WSNF8553A421 24DC

WSNF8553A321 24DC

WSNF8553A309MO

Pictures Show

Detail Showcase
