Features

1.A specially designed snubber offers slower disc closing speed to protect systems against water hammer damage.

2.Pressure spike due to water hammer is reduced to a point eliminating the need for suppressors or other controls in most water systems

3.Hot water service to 150 psi (10 Bar) differential @ 210°F (100°C)

4.Pilot-operated, normally open, or normally closed models are available with a full range of pipe sizes up to 2 1/2.

5.Broad range of standard AC and DC voltages available

Specifications

Valve Actuation: Solenoid

Body Material: Brass

Media: Water

Pipe / Port Size: 3/8 "; 3/4 "; 1 "; 1 1/4 "; 1 1/2 "; 2 "; 2 1/2 "

Port Type: NPTF

Function: 2 way - 2/2 Normally Closed; 2 way - 2/2 Normally Open

Voltage: 110 AC; 115 AC; 12 DC; 120 AC; 120 DC; 208 AC; 220 AC; 230 AC; 24 AC; 24 DC; 240 AC; 240 DC; 440 AC; 48 DC; 480 AC; 6 DC - 50/60

Max Differential / Max Operating Pressure: Vacuum to 10.3 Bar; Vacuum to 150 PSIG; 150-500 PSIG; 10.3-34.5 Bar

Operating Environment: Corrosive; Hazardous; Indoor; Outdoor
