Features

1.Delivers the industry's best flow per pipe size with a 2 Cv for 1/4-inch size and a 15.5 Cv for 1"

2.Low-power solenoid versions are available with UL, CSA, ATEX, and IECEX hazardous location approvals that consume only 1.4 watts. A 0.55-watt solenoid option is ideal for remote applications requiring alternate energy sources

3.Extensive manual and low-temperature models are suitable for harsh application environments

4.Solenoid options with factory-sealed leads reduce installation cost

Specifications

Valve Actuation：Pneumatic - Air Pilot, Pneumatic - Latching, Solenoid, Solenoid - Direct Acting, Solenoid - Latching

Body Material：Stainless Steel, Brass

Media：Air, Inert Gas, Natural Gas

Pipe / Port Size：1/4 "; 3/8 "; 1/2 "; 3/4 "; 1 "

Port Type：NPTF

Function：3 way - 3/2 Normally Closed, Closed Center, 3 way - 3/2 Normally Open, 3 way - 3/2 Normally Closed

Flow：From 1.8 to 15.5 Cv (1.55 to 13.4 Kv)

Voltage：120 AC, 12 DC, 24 DC | 50, 60

Max Differential / Max Operating Pressure

Vacuum to 150 PSIG
