Specifications

DIN EN 1092-2

ASME B16.5

Size Range:

1" - 8"

DN 25 - DN 250

Pressure Class Range:

PN 10

PN 16

Class 150

Seating Material:

PTFE

PTFE-glass-reinforced

PTFE-conductive
