Features

1.Unique integrated bypass valve simplifies the high pressure system design which results in fewer components and leak paths for added safety

2.The addition of the 50-4000 Series to HPU units simplifies complex start up procedures while decreasing down time associated with filling long umbilicals

3.Controls large variations in flow rates at pressures up to 20,000 psig / 1379 bar

4.New stem and seal design extends regulator service life in crucial high pressure water-based hydraulic applications

Specifications

Maximum Inlet Pressure：10,000, 15, 000, 20,000 psig / 690, 1034, 1379 bar

Outlet Pressure Ranges：9000 to 20,000 psig / 621 to 1379 bar

                                         8000 to15,000 psig / 552 to 1034 bar

                                         6000 to 15,000 psig / 414 to 1034 bar

                                         4000 to 10,000 psig / 276 to 690 bar

                                         2000 to 6000 psig / 138 to 414 bar

                                         2000 to 4000 psig / 138 to 276 bar

                                         1700 to 2500 psi

Body Material：316 Stainless Steel, Nitronic® 60 (20,000 psig / 1379 bar Inlet)

The  Related Products:

TESCOM Model Recommendations:

Pressure Reducing Valves:

26-1765-24-247

26-2091A24S272

44-2263-241

44-2263-241 (duplicate entry)

44-2260-942-151

44-4660S94-018

44-2263-242

26-1065-24

26-1766-26

26-1064-24

26-1062-24

26-1063-24

44-1123-24

26-1765-24-071

44-1163-24

54-2062D24

Control Valves:

44-1116-24

26-1065-24-760

44-2263-241

26-1061-24

26-1765-26

26-1764-26

26-1766-26

44-1767-24

SG1P6162

Picture show:
