Fisher 846 Electro-Pneumatic Transducer
The Fisher 846 transducer converts an electrical output signal from a controller to a pneumatic signal necessary to operate a control valve actuator or pneumatic positioner. Using electronic feedback, the transducer can correct for error-producing effects, such as variations in supply pressure and downstream leakage.
Features
1.The low-mass pilot stage, mechanically damped deflector bar, and rugged construction provide stable performance in vibration.
2.Large diameter nozzles, free-flow pilot stage design, and large internal pneumatic supply passages provide excellent tolerance to reducing the effects of contaminant build-up and erosion.
3.The electronic feedback control network monitors the pneumatic output signal, detects any input-output deviations and corrects them.
4.Major mechanical and electrical components are incorporated into a single field-replaceable master module.
Specifications
Communication Protocol
4-20mA Analog
Data Interface
Wired
Diagnostics
No
Input Signal
Electric
Mounting Type
Remote Mount, Actuator Mount
Operating Temperature
Standard Temperature
Position Control
Modulating Control
Pictures show
