Features

1.Resists Hydrate Formation and Regulator Freeze-up

2.Durable

3.Ease of Maintenance

4.High Pressure Capabilities

5.NACE Construction Available

Specifications

Body Size and End Connection Style

Inlet: 1 NPT

Outlet: 1/4 NPT

Outlet Pressure Ranges

Type 1305C: 1 to 75 psig / 0.069 to 5.2 bar, 5 to 150 psig / 0.34 to 10.3 bar, 10 to 225 psig / 0.69 to 15.5 bar

Type 1305D: 200 to 500 psig / 13.8 to 34.5 bar

Pressure Registration

Internal

Temperature Capabilities

20 to 200°F / -29 to 93°C

Approximate Weight

6 Pounds / 3 kg

Additional Technical Data

For additional technical information, contact your local Sales Office or refer to technical documentation.
