FEATURES:

1.Flanged body design eliminates exposed line flange bolting, reduces alignment and installation time, and promotes secure valve installations and piping integrity.

2.The solid HD ball seal construction provides long service life in demanding applications.

3.Precise contouring of the Vee-Ball provides a modified equal percentage flow characteristic.

4.Materials are available for applications involving sour liquids and gases. These constructions comply with NACE MR0175-2002, MR0175-2003, MR0103, and MR0175/ISO 15156.

5.Ball seal inspection and replacement is done at the valve body inlet, without removing the actuator or disassembling the valve.

SPECIFICATIONS:

Certifications

SIL capable, ATEX, CUTR, PED, CRN, Fugitive Emission, NACE

Critical Service

Noise Abatement, Cavitation, Dirty Service, Erosive, Low Flow, General Service

Flow Characteristics

Equal Percentage

Material

Carbon Steel, Stainless, Duplex, Alloy

Operating Temperature

Standard Temperature

Pressure Class

PN, ASME

Process Connection Type

Flanged

Picture show
