FEATURES

1.Removable groove pin allows quick, easy valve plug replacement.

2.D4 valves are available with tungsten carbide trim for erosive service.

3.Compact design allows installation where space is a premium. Screwed valve bodies feature compact face-to-face dimensions while flanged valve bodies conform to ISA-75 standards for maximum versatility.

4.Hammer nut bonnet/body joint allows repair or maintenance with a minimum of tools, without removing the valve body from the piping system. Seat ring can be removed with a standard socket.

5.Bonnet has an integral flange that accepts hammer nut force when making the bonnet-to-body connection. There are no snap rings subject to possible failure in sour service or in atmospheric corrosion.

6.Micro-Form trim is standard for throttling or on/off service at no extra cost.

SPECIFICATIONS

Certifications

PED, CUTR, ATEX, CRN

Critical Service

Dirty Service, Erosive

Flow Characteristics

Equal Percentage

Material

Carbon Steel

Operating Temperature

Standard Temperature

Pressure Class

ANSI CL150, ANSI CL300, ANSI CL600, ANSI CL1500

Process Connection Type

Threaded, Flanged, RTJ

Shutoff Class

Class IV (FCI 70-2)

Valve Size

NPS 1, NPS 2

Valve Size Standard

NPS
