FEATURES

1.The seat ring design self-centers, self-laps, and dynamically aligns with V-notch ball, giving superior cycle life.

2.No special orientation, precision clamping, or repetitive centering of V-notch ball and seat ring is required when tightening the retainer, promoting accurate alignment and easy assembly.

3.Precise contouring of V-notch ball provides a modified equal percentage flow characteristic.

4.Unrestricted, straight-through, flow design provides greater capacity than many conventional globe and rotary eccentric plug valves.

SPECIFICATONS

Certifications

SIL capable, ATEX, CUTR, PED, CRN, Fugitive Emission, NACE

Critical Service

Cavitation, Dirty Service, Erosive, Low Flow, General Service

Flow Characteristics

Equal Percentage

Material

Carbon Steel, Stainless, Alloy

Operating Temperature

Standard Temperature

Pressure Class

PN, ASME

Process Connection Type

Flanged

Shutoff Class

Class IV (FCI 70-2)

Pictures show
