FEATURES

1.Includes a pipe plug that allows for the D2T body to be configured as a globe valve or angle valve.

2.1 NPT end connections are available.

3.Features a CL900 (2250 psig) pressure rating.

4.FloPro field selectable flow rate for 1/4, 3/8, and 1/2 inch port size.

5.Solid Alloy 6 erosive service trim.

6.Has a full 2250 psig pressure drop capability.

7.Valve is NACE service ready.

SPECIFICATIONS

Certifications

PED, ATEX, CRN

Critical Service

General Service

Flow Characteristics

Characterization

Material

Carbon Steel

Operating Temperature

Standard Temperature

Pressure Class

ASME CL900

Process Connection Type

Threaded

Shutoff Class

Class IV (FCI 70-2)

Valve Size

NPS 1

Valve Size Standard

NPS
